AdvantechSmartFlex, Global, 5x ETH, WIFI, PoE PSE, Metal
Rp17.578.848
Deskripsi
SPESIFICATION
| Category | Attribute | Value |
| Power | Power Supply | 10 to 60 V DC |
| Certifications | Carriers | – / – / – |
| Certifications | CCC | – |
| Certifications | CE | Yes |
| Certifications | E8 | – |
| Certifications | FCC/IC | Yes |
| Certifications | KCC | – |
| Certifications | RCM | Yes |
| Certifications | UL 60950-1 | – |
| Certifications | UL C1D2/Atex | Yes |
| Certifications | UL MX CoC | – |
| General | 3G/HSPA+ | – |
| General | GPRS/EDGE | – |
| General | LTE cat.1 | – |
| General | LTE cat.3 | – |
| General | LTE cat.4 | – |
| General | LTE450 | – |
| General | Twin module | – |
| Mechanical | Case | Metal |
| Mechanical | Dimensions [mm] | 55 x 97 x 125 |
| Mechanical | Weight | 380 |
| Region | APAC | Yes |
| Region | AUS/NZ | Yes |
| Region | China | – |
| Region | EMEA | Yes |
| Region | Global | Yes |
| Region | GSM-R | – |
| Region | Korea | – |
| Region | LATAM | Yes |
| Region | LTE450 | – |
| Region | NAM | Yes |
| Port, LED, Anntena | Cellular Antennas | – |
| Port, LED, Anntena | GPS Antenna | – |
| Port, LED, Anntena | LED Indicators | PWR, USR, POE, IN0, IN1, OUT, ETH |
| Port, LED, Anntena | MicroSD | Yes |
| Port, LED, Anntena | Mounting | DIN |
| Port, LED, Anntena | SIM slots | – |
| Port, LED, Anntena | WiFi Antennas | – |
| WiFi / GPS / PoE | GPS | – |
| WiFi / GPS / PoE | PoE PD | – |
| WiFi / GPS / PoE | PoE PSE | – |
| WiFi / GPS / PoE | WiFi 2.4 GHz / WiFi 2.4 GHz SMA | – / – |
| WiFi / GPS / PoE | WiFi 2.4/5 GHz | – |
| Interfaces | DUST | – |
| Interfaces | ETH port(s) | 5 |
| Interfaces | MBUS / WMBUS | – / – |
| Interfaces | RS232 | – |
| Interfaces | RS232 / RS485 / RS422 | – / – / – |
| Interfaces | RS422 | – |
| Interfaces | RS485 | – |
| Interfaces | USB | Yes |
| I/O ports | CNT (4x DI, 2x AI, 1x DO) | – |
| I/O ports | I/O 1x DI + 1x DO | – |
| I/O ports | I/O 2x DI + 1x DO | Yes |
| Enviroment | Humidity | 0 to 95 % |
| Enviroment | Operating Temperature | –40 °C to +75 °C |
| Enviroment | Storage Temperature | –40 °C to +85 °C |
| Cellular Module | CDMA Bands | – |
| Cellular Module | GSM Bands | – |
| Cellular Module | LTE Bands | – |
| Cellular Module | UMTS Bands | – |
| Power | Power Input (DC) | 10 ~ 60 VDC |
| Power | Sleep Mode | Yes |
| Interface | ETH Port(s) | 5 |
| Interface | I/O | 2 x DI + 1 x DO |
| Interface | MicroSD | Yes |
| Interface | USB | 1 |
| Environment | Humidity (Operating Range) | 0~95% |
| Environment | Temperature (Operating Range) | -40 ~ 75°C (-40 ~ 167°F) |
| Mechanism | Dimensions (W x H x D) | 125 x 55 x 97 mm |
| Mechanism | Mounting (DIN-rail) | Yes |
| Warranty | Warranty Period | 3 years |
| Region | Global | Yes |
| Packaging | Accessories | Without accessories |
Informasi Tambahan
| Brand |
Advantech |
|---|
