Name: Cisco Nexus 3172TQ Switch, 32 10GBase-T RJ-45 and 6 QSFP+ ports (N3K-C3172TQ-32T)
SKU: N3K-C3172TQ-32T
Availability: InStock

Cisco Nexus 3172TQ Switch, 32 10GBase-T RJ-45 and 6 QSFP+ ports (N3K-C3172TQ-32T)

Rp315.484.200

Description	Specification
Physical	● 1RU fixed form factor ● Cisco Nexus 3172TQ-32T: 48 x 10 Gigabit Ethernet ports (32 10GBASE-T and 6 QSFP+) ◦ 32 RJ-45 ports support 100 Mbps and 1 and 10 Gigabit Ethernet ◦ 6 QSFP ports support 4 x 10 Gigabit Ethernet or 40 Gigabit Ethernet each ● Redundant fans (3+1) ● 2 redundant power supplies ● Management, console, and USB flash-memory ports
Performance	● 1.4-Tbps switching capacity ● Forwarding rate of up to 1 bpps ● Line-rate traffic throughput (both Layer 2 and 3) on all ports ● Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames)
Hardware tables and scalability	Number of MAC addresses	288,000
	Number of VLANS	4096
	Number of spanning-tree instances	● RSTP: 512 ● MSTP: 64
	Number of ACL entries	● 4000 ingress ● 1000 egress
	Routing table	● 16,000 prefixes and 16,000 host entries ^* ● 8000 multicast routes ^*
	Number of EtherChannels	64 (with vPC)
	Number of ports per EtherChannel	32
	System memory	4 GB (3172PQ, 3172TQ, and 3172TQ-32T)
	System memory	8 GB (3172PQ-XL and 3172TQ-XL)
	Buffer size	12 MB shared
	Boot flash	2 GB (3172PQ, 3172TQ, and 3172TQ-32T) 16 GB (3172PQ-XL and 3172TQ-XL)^**
Power	Number of power supplies	2
	Power supply types	● AC (forward and reversed airflow) ◦ – N2200-PAC-400W and N2200-PAC-400W-B (PQ models) ◦ – NXA-PAC-500W and NX-PAC-500W-B (TQ models) ● DC (forward and reversed airflow) ◦ – N2200-PDC-400W and N3K-PDC-350W-B (PQ models) ◦ – NXA-PDC-500W and NX-PDC-500W-B (TQ models)
	Typical operating power	● 3172PQ and 3172PQ-XL: 143 W ● 3172TQ and 3172TQ-XL: 360 W
	Maximum power	3172PQ and 3172PQ-XL: 293W 3172TQ and 3172TQ-XL: 440W
	AC PSUs ● Input voltage ● Frequency ● Efficiency	● 100 to 240 VAC ● 50 to 60 Hz ● 89 to 91% at 220V
	DC PSUs ● Input voltage ● Maximum current (PSU output – System input) ● Efficiency	● –40 to –72 VDC ● 33A (400W unit), 42A (500W unit) ● 85 to 88%
	Typical heat dissipation	● 3172PQ and 3172PQ-XL: 488 BTU/hr ● 3172TQ and 3172TQ-XL: 1228 BTU/hr
	Maximum heat dissipation	● 3172PQ and 3172PQ-XL: 1000 BTU/hr ● 3172TQ and 3172TQ-XL: 1501 BTU/hr
Cooling	● Forward and reversed airflow schemes: ◦ Forward airflow: Port-side exhaust (air enters through fan-tray and power supplies and exits through ports) ◦ Reversed airflow: Port-side intake (air enters through ports and exits through fan-tray and power supplies) ● Redundant fans ● Hot swappable (must swap within 1 minute)
Sound	Measured sound power (maximum) ● Fan speed: 40% duty cycle ● Fan speed: 70% duty cycle ● Fan speed: 100% duty cycle	● 64.9 dBA ● 69.3 dBA ● 76.7 dBA
Environment	Dimensions (height x width x depth)	● 3172PQ and 3172PQ-XL: 1.72 x 17.3 x 17 in. (4.4 x 43.9 x 43.2 cm) ● 3172TQ, 3172TQ-32T and 3172TQ-XL: 1.72 x 17.3 x 19.7 in. (4.4 x 43.9 x 50.5 cm)
	Weight	● 3172PQ and 3172PQ-XL: 18.6 lb (8 4 kg) ● 3172TQ, 3172TQ-32T and 3172TQ-XL: 22.0 lb (10 kg)
	Operating temperature	● 32 to 104°F (0 to 40°C)
	Storage temperature	● -40 to 158°F (-40 to 70°C)
	Operating relative humidity	● 10 to 85% noncondensing ● Up to 5 days at maximum (85%) humidity ● Recommend ASHRAE data center environment
	Storage relative humidity	● 5 to 95% noncondensing
	Altitude	● 0 to 10,000 ft (0 to 3000m)

Cisco Nexus 3172TQ Switch, 32 10GBase-T RJ-45 and 6 QSFP+ ports (N3K-C3172TQ-32T)

Cisco Nexus 3172 Series Datasheet.pdf
