| Camera | |
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | 120 dB |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Lens | |
| Iris Type | Fixed |
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
| Focal Length & FOV | · 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 123°
· 4 mm, horizontal FOV 83°, vertical FOV 45°, diagonal FOV 98° · 6 mm, horizontal FOV 53°, vertical FOV 28°, diagonal FOV 62° |
| Aperture | F1.4 |
| Lens Mount | M12 |
| Iluminator | |
| IR Range | Up to 30 m |
| Wavelength | 850 nm |
| Network | |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| User/Host | Up to 32 users,3 levels: Administrator, Operator and User |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Network Storage | · MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
· Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Video | |
| Max. Resolution | 2688 × 1520 |
| Main Stream | · 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
· 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub Stream | · 50 Hz: 25 fps (640 × 480, 640 × 360)
· 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Third Stream | · 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
· 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) · *Third stream is supported under certain settings. |
| Video Compression | · Main stream: H.265/H.264
· Sub-stream: H.265/H.264/MJPEG · Third stream: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | Support 1 fixed region for main stream and sub-stream |
| Image | |
| Day/Night Switch | Day/Night/Auto/Schedule |
| Image Enhancement | BLC/3D DNR/HLC |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| SNR | ≥ 52 dB |
| Deep Learning Function | |
| Face Capture | Yes |
| Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
